About
Description
- 2.0mm pretravel
- 3.6mm total travel
- L4 POM blend stem with flat pole tip
- PA12 top housing
- PA66 and 20% fiberglass bottom housing
- 20mm spring
- 45g switch has a bottom out force of 53g
- 37g switch has a bottom out force of 45g
Characteristics
Stem Type
MX
Feel
Linear
Mount Type
PCB mount
Switch Pin Count
5
Force Variance
5 cN
Operating Position
2.0 mm
Full Travel
3.6 mm
Stem Color
Off-White
Top Housing Color
Blue
Bottom Housing Color
Blue
Spring Length
20mm
37g
KG_AZSB37
45g
KG_AZSB45
Description
- 2.0mm pretravel
- 3.6mm total travel
- L4 POM blend stem with flat pole tip
- PA12 top housing
- PA66 and 20% fiberglass bottom housing
- 20mm spring
- 45g switch has a bottom out force of 53g
- 37g switch has a bottom out force of 45g
Characteristics
Stem Type
MX
Feel
Linear
Mount Type
PCB mount
Switch Pin Count
5
Force Variance
5 cN
Operating Position
2.0 mm
Full Travel
3.6 mm
Stem Color
Off-White
Top Housing Color
Blue
Bottom Housing Color
Blue
Spring Length
20mm
37g
KG_AZSB37
45g
KG_AZSB45
Keygeek
by
Keygeek
Keygeek Azure Sky Blue Linear PCB Mount Switch
- Regular price
- $0.35
- Sale price
- $0.35
- Regular price
-
$0.00
In Stock
Available for Pre-Order!
Pickup available at MK Tech Center
Usually ready in 1 hour
SKU: KG_AZSB45
Qty Discounts Available!
70+: 2% off, 90+: 3% off, 110+: 5% off
